D-Link DMS-105 5-Port Multi-Gigabit Unmanaged Switch
Product code: 11775022 // MPN: DMS-105/E // EAN: 0790069469305
Similar products
Small switch. Multi-Gigabit Ethernet.
Maximise network throughput with 2.5Gbps Multi-Gigabit Ethernet on each port of this compact 5-port switch. Whether it’s to connect to your core or create a network between devices. now you can easily start sharing an internet connection. files. music. and video. or for gaming without bottlenecks.
2.5 Gigabit Ethernet
Save time transferring large files and improve sharing and productivity
Effortless multi-Gigabit networking
Easily upgrade or extend your home or small business network
Compact Metal Housing
Sturdy. compact metal housing with fanless design for silent operation
Energy Efficient Design
Automatic power saving features to reduce power usage
Plug-and-pay convenience.
The DMS-105 is a plug-and-play device that requires no configuration to get started. Plug-and-play makes it easy to instantly create a network without any technical knowledge.
Effortless traffic optimisation.
With 2.5 Gigabit transfer speeds from every port. you can rapidly transfer files between connected servers and network attached storage (NAS) to computers. The Quality of Service (QoS). and Flow Control features automatically prioritises important data for efficient delivery. And the IGMP Snooping function reduces unwanted multicast traffic so you can enjoy seamless video streaming and IPTV viewing experiences.
Designed for life. built to last.
The DMS-105 has a sturdy and compact metal housing to ensure the product can withstand wider operating temperatures by helping to dissipate heat and reduce stress on internal components.
Energy Saving.
The DMS-105 is designed with energy efficiency in mind. The fanless design eliminates a common point of failure and means the switch can be placed virtually anywhere and operate silently. The Link Status detection feature of the switch saves power by automatically powering down ports that are inactive or not connected. and it supports the IEEE 802.3az Energy-Efficient Ethernet standard.
Ready for Wi-Fi 6.
You can add a Wi-Fi 6 Access Point to your network to any of the 2.5 Gbps ports to maximise throughput and speed. Multi-Gigabit Ethernet eliminates potential bottlenecks with Wi-Fi 6 Access Points. allowing your network to take full advantage of the efficiency and speeds provided by Wi-Fi 6.
Management features
Switch type: Unmanaged
Switch layer: L2
Feature: Quality of Service (QoS) support
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 5
Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)
2.5G Ethernet (copper) ports quantity: 5
Network
Networking standards: IEEE 802.1p. IEEE 802.3ab. IEEE 802.3az. IEEE 802.3bz. IEEE 802.3u. IEEE 802.3x
Feature: Flow control support
Feature: Auto MDI/MDI-X
Feature: MAC address auto-learning supported
Data transmission
Switching capacity: 25 Gbit/s
Forwarding rate: 18.6 Mpps
MAC address table: 4000 entries
Feature: Store-and-forward
Packet buffer memory: 8.1 MB
Security
Feature: IGMP snooping
Multicast features
Feature: Multicast support
Design
Feature: Stackable
Product colour: Black
LED indicators: Activity. Link. Power
Performance
Feature: Fanless
Mean time between failures (MTBF): 765190 h
Power
Power source: DC
Feature: Power supply included
DC input voltage: 12 V
Input current: 1 A
Power consumption (typical): 4.918 W
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -10 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%
Heat dissipation: 16.78 BTU/h
Weight & dimensions
Width: 100.5 mm
Depth: 82 mm
Height: 28 mm
Weight: 238.6 g
Sustainability
Feature: Sustainability compliance
Certificates
Compliance certificates: BSMI. CE. Low Voltage Directive (LVD). RoHS
