POWER AND THROUGHPUT
Edge to core stackable platform. from 1 Gigabit to 100 Gigabit. all within 15.75in (40cm) of depth.
Groundbreaking AV GUI
A simplified user interface makes it easy to assign configuration profiles to each port.
Multicast in an Instant
NETGEAR IGMP Plus™ provides multicast functionality right out of the box for most AV over IP applications.
Sleek. Quiet Design
Less fan noise. and mounting ears included for rack mounting.
Automatic Configuration
Auto-trunk and auto-LAG functionality auto connects with other M4350 (and M4250) switches.
FAST. EASY CONFIGURATION FOR AV PROS
A streamlined interface enables factory default AV settings or user-specified AV profiles to be assigned to individual ports with just a few clicks.
FOCUS ON THE EVENT NOT FAN NOISE
Most models have quiet mode which greatly reduces fan noise.
DESIGNED FOR AV OVER IP RIGHT OUT OF THE BOX
With built-in NETGEAR IGMP Plus™. there's little-to-no setup required for flawless Video over IP delivery. Enable multicasting right out of the box.
Management features
Switch type: Managed
Switch layer: L3
Feature: Quality of Service (QoS) support
Feature: Web-based management
Feature: ARP inspection
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000)
10G Ethernet (copper) ports quantity: 24
SFP+ module slots quantity: 8
SFP28 ports quantity: 8
Network
Feature: 10G support
Feature: Full duplex
Feature: Policy-based routing
Feature: Flow control support
Feature: Link aggregation
Feature: Broadcast storm control
Feature: Rate limiting
Feature: Spanning tree protocol
Feature: 6to4 tunnel
IPv4 routes: 512
IPv6 routes: 256
Feature: VLAN support
Virtual LAN features: MAC address-based VLAN. Private VLAN. Voice VLAN
Number of VLANs: 4093
Data transmission
Switching capacity: 1040 Gbit/s
Throughput: 773.76 Mpps
MAC address table: 16000 entries
Feature: Store-and-forward
Latency (10 Gbps): 2.7 µs
Feature: Jumbo frames support
Jumbo frames: 12000
Packet buffer memory: 64 MB
Security
DHCP features: DHCP Option 150. DHCP Option 66. DHCP Option 67. DHCP relay. DHCP server. DHCP snooping
Feature: Access Control List (ACL)
Access Control List (ACL) egress: 1023
Access Control List (ACL) ingress: 511
Feature: IGMP snooping
Feature: IGMP proxy
Feature: MAC address filtering
Feature: Static port security
Feature: Loop protection
Feature: BPDU filtering/protection
Authentication: Guest VLAN. MAC-based authentication
Feature: Root protection
Feature: Password protection
Feature: DoS attack prevention
Authentication type: RADIUS. TACACS+
Queue scheduling algorithms: Strict Priority Queue (SPQ). Weighted random early detection (WRED)
Multicast features
Feature: Multicast support
Feature: Multicast Listener Discovery (MLD) snooping
Protocols
Management protocols: SNMP V1. V2. V3
Feature: GARP VLAN Registration Protocol (GVRP)
Routing protocols: OSPF. OSPFv2. OSPFv3. RIP. RIP-1. RIP-2
Design
Feature: Rack mounting
Feature: Stackable
Form factor: 1U
Product colour: Black
Feature: LED indicators
Airflow direction: Front-to-back airflow
Performance
Feature: Built-in processor
Processor model: ARM Cortex-A57
Processor frequency: 1800 MHz
Memory type: DDR4-SDRAM
Internal memory: 4096 MB
Flash memory: 512 MB
Feature: sFlow
Power
Power source: AC
Feature: Power supply included
Power consumption (typical): 151.8 W
Power consumption (max): 464 W
Power over Ethernet (PoE)
Feature: Power over Ethernet (PoE)
Power over Ethernet 4PPoE (PoE++) ports quantity: 24
Power over Ethernet (PoE) power per port: 90 W
Total Power over Ethernet (PoE) budget: 1770 W
Other features
Power supply: 750 W
Operational conditions
Operating temperature (T-T): 0 - 45 °C
Storage temperature (T-T): -20 - 70 °C
Operating relative humidity (H-H): 0 - 90%
Storage relative humidity (H-H): 0 - 95%
Operating altitude: 0 - 3000 m
Non-operating altitude: 0 - 3000 m
Weight & dimensions
Width: 440 mm
Depth: 400 mm
Height: 43.2 mm
Weight: 7.24 kg
Packaging content
Cables included: AC. USB Type-C
Feature: Quick start guide
Feature: Rack mount kit
Packaging data
Included power plug types: EU. UK. NA
Sustainability
Feature: Sustainability compliance
Certificates
Compliance certificates: BSMI. CCC. CE. Federal Communications Commission (FCC). Low Voltage Directive (LVD)
