Switch 4x FE IES-0510 1xSC
Product code: 11727622 // MPN: IES-0510 // EAN: 4015867181607
Similar products
LevelOne IES-0510 Industry Ethernet Switch provides 4 ports of 10/100Base-TX Ethernet plus 1 port 100FX Multimode SC fiber to enable high speed network at mission-critical environment. This device is designed to be mounted on an industry standard DIN-rail. plus the clearly visible status LEDs provide simple monitoring of port link activity.
Cost Effective
This device operates under -10 to 60 Celsius (-14 to 140 Fahrenheit) temperature that offers optimal suitability for industrial applications at low cost while maintaining all components built to withstand harsh environment applications without compromise reliability and stability.
Safety
With UL60950 standard complied that gives basic protection against electric shock. fire spread from within. ignition and burning. current circuit hazardous under normal and fault condition. As well as set of compliances to meet many EMC. isolation. vibration and shock standards.
Plug & Play
This device is designed for the demanding industrial environments at businesses in need of instant connectivity with no setup or configure required. truly plug and play.
Management features
Switch type: Unmanaged
Feature: Quality of Service (QoS) support
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 4
Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
Fiber optic connector: SC
Network
Networking standards: IEEE 802.1p. IEEE 802.3. IEEE 802.3az. IEEE 802.3u. IEEE 802.3x
Copper ethernet cabling technology: 10BASE-T. 100BASE-TX
Feature: Full duplex
Feature: Auto MDI/MDI-X
Feature: Auto-negotiation
Optical fiber
Fiber ethernet cabling technology: 100BASE-FX
Fiber type: Multi-mode
Data transmission
MAC address table: 2048 entries
Feature: Store-and-forward
Packet forwarding rate (100 Mbps): 148810 pps
Packet forwarding rate (10 Mbps): 14880 pps
Packet buffer memory: 0.384 MB
Design
Product colour: Black
Housing material: Plastic
LED indicators: Activity. Link. Speed
International Protection (IP) code: IP30
Safety: UL60950-1
Performance
Mean time between failures (MTBF): 1071085 h
Power
Input voltage: 12 - 48 V
Power consumption (max): 4.3 W
Operational conditions
Operating temperature (T-T): -10 - 60 °C
Storage temperature (T-T): -25 - 85 °C
Operating relative humidity (H-H): 5 - 95%
Weight & dimensions
Width: 26 mm
Depth: 70 mm
Height: 110 mm
Weight: 200 g
Packaging content
Feature: Quick start guide
Packaging data
Package type: Box
Package width: 180 mm
Package depth: 79 mm
Package height: 221 mm
Package weight: 460 g
Logistics data
Country of origin: Taiwan
Harmonized System (HS) code: 85176990
Cost Effective
This device operates under -10 to 60 Celsius (-14 to 140 Fahrenheit) temperature that offers optimal suitability for industrial applications at low cost while maintaining all components built to withstand harsh environment applications without compromise reliability and stability.
Safety
With UL60950 standard complied that gives basic protection against electric shock. fire spread from within. ignition and burning. current circuit hazardous under normal and fault condition. As well as set of compliances to meet many EMC. isolation. vibration and shock standards.
Plug & Play
This device is designed for the demanding industrial environments at businesses in need of instant connectivity with no setup or configure required. truly plug and play.
Management features
Switch type: Unmanaged
Feature: Quality of Service (QoS) support
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 4
Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100)
Fiber optic connector: SC
Network
Networking standards: IEEE 802.1p. IEEE 802.3. IEEE 802.3az. IEEE 802.3u. IEEE 802.3x
Copper ethernet cabling technology: 10BASE-T. 100BASE-TX
Feature: Full duplex
Feature: Auto MDI/MDI-X
Feature: Auto-negotiation
Optical fiber
Fiber ethernet cabling technology: 100BASE-FX
Fiber type: Multi-mode
Data transmission
MAC address table: 2048 entries
Feature: Store-and-forward
Packet forwarding rate (100 Mbps): 148810 pps
Packet forwarding rate (10 Mbps): 14880 pps
Packet buffer memory: 0.384 MB
Design
Product colour: Black
Housing material: Plastic
LED indicators: Activity. Link. Speed
International Protection (IP) code: IP30
Safety: UL60950-1
Performance
Mean time between failures (MTBF): 1071085 h
Power
Input voltage: 12 - 48 V
Power consumption (max): 4.3 W
Operational conditions
Operating temperature (T-T): -10 - 60 °C
Storage temperature (T-T): -25 - 85 °C
Operating relative humidity (H-H): 5 - 95%
Weight & dimensions
Width: 26 mm
Depth: 70 mm
Height: 110 mm
Weight: 200 g
Packaging content
Feature: Quick start guide
Packaging data
Package type: Box
Package width: 180 mm
Package depth: 79 mm
Package height: 221 mm
Package weight: 460 g
Logistics data
Country of origin: Taiwan
Harmonized System (HS) code: 85176990
