RACK CABINETS

The DIGITUS® Dynamic Basic series has been manufactured. designed and developed for the high demands of IT infrastructure

- Roof is prepared to accommodate a fan element (punched-out mounts)
- Lockable swivel lever handle on the front door
- Base with punched cable inlet. covered with screwed plate

The Dynamic series network cabinets have been developed for simple and particularly cost-optimized network expansion. Sophisticated positioning of the cable inlets ensures effortless installation depending on the application. In the floor chassis. this is located centrally at the rear. protected by a screw-fastened cover plate. Enclosures from 800 mm width are additionally extended by cable inlets with plastic covers on the left and right. These are also integrated in the roof (1 x for 600 mm enclosure width. 3 x for 800 mm enclosure width). The roof chassis is also provided with a punched-out area to accommodate a fan module. Two pairs of galvanized 483 mm (19") profile rails. labelled with height units that can be read in both directions. are installed inside. They can be adjusted in depth and are connected to additional depth braces in the cabinet. Each enclosure is a robust steel construction made from sheet steel up to 1.5 mm thick. The coloring takes the form of electrostatic powder coating in the standard colors grey (RAL 7035) and black (RAL 9005). Removable side and rear panels as well as the lockable and removable front door improve accessibility. The door hinges can be changed. Furthermore. the cabinets can be completely dismantled if required thanks to the demountable design.

Features
Type: Freestanding rack
Maximum weight capacity: 600 kg
Product colour: Grey
Back door construction: Steel
Front door construction: Glass
Feature: Side panels included
International Protection (IP) code: IP20
Weight & dimensions
Size (imperial): 48.3 cm (19")
Width: 600 mm
Depth: 600 mm
Height: 1164 mm
Packaging data
Package width: 650 mm
Package depth: 650 mm
Package volume: 509112 cm³
Package weight: 45 kg
Logistics data
UK Trade Tariff code: 94032080
Country of origin: Turkey
Harmonized System (HS) code: 85381000
