ENCLOSURES

BioniX P140
Pressure-optimised 140 mm Gaming Fan with PWM PST

The BioniX P140 fan features completely redesigned fan blades and is optimised for high static pressure. Thus. the BioniX P140 is especially effective when used on heatsinks and with higher air resistance.
The wide RPM range from 200 to 1950 RPM can be regulated seamlessly and synchronously with other fans thanks to ARCTIC's PWM Sharing Technology (PST).
The newly developed motor with a low coil temperature significantly increases the life span of the fan. Therefore we have extended the warranty to 10 years.

Performance
Suitable location: Computer case
Type: Fan
Fan diameter: 14 cm
Supported processor sockets: Not supported
Compatible processor series: Not supported
Rotational speed (min): 200 RPM
Rotational speed (max): 1950 RPM
Noise level: 0.45 sone
Maximum airflow: 77.6 cfm
Airflow: 131.92 m³/h
Maximum air pressure: 2.85 mmH2O
Feature: Pulse-width modulation (PWM) support
Bearing type: Fluid Dynamic Bearing (FDB)
Design
Product colour: Grey. White
Number of fans: 1 fan(s)
Number of fan blades: 5
Fan connector: 4-pin + 4-pin
Power
Power consumption (typical): 1.8 W
Voltage: 12 V
Rated current: 0.15 A
Weight & dimensions
Width: 140 mm
Depth: 28 mm
Height: 140 mm
Weight: 181 g
Cable length: 0.4 m
Package width: 148 mm
Package depth: 35 mm
Package height: 148 mm
Package weight: 230 g
Packaging content
Package type: Box
Feature: Screws included
Number of screws: 4
Other features
Mounting hole pattern (W x D): 125 x 125 mm
Country of origin: China
Logistics data
Harmonized System (HS) code: 84733080
