PC MONITORS

The ViewSonic® CDE5520 is a 55” premium 4K large format presentation display. With features including a razor-sharp resolution of 3840 x 2160. 450-nit high brightness. 178-degree ultra-wide viewing angles. 2 x 10W speakers. and wireless screen sharing. the display transforms meeting rooms into dynamic communications hubs. The built-in ViewBoard® screen sharing software*. ViewBoard® Cast (along with the optional ViewSonic® vCastSender app). enables both on-site and online users to participate in conferences and simultaneously share content. Equipped with twin dual-core processors. 3GB RAM. and 16GB of internal memory. the CDE5520 can play multimedia from internal storage or a USB flash drive. And with remote configuration and content management system support. the ViewSonic® CDE5520 is also suitable for a wide array of diverse signage applications. *Chrome. Android. Windows. Mac OS. and iOS compliant

Multiple Ways to Connect and Share

Connect wirelessly through your network or directly to the display. Use the ViewBoard Cast™ screen sharing software along with the web-based myViewBoard® Display app to allow up to four participants (on-site and remote) to connect and share their content regardless of what OS platform they are using (Windows. MacOS. Chrome OS. Android. iOS). In addition. AirPlay. Miracast and the optional ViewBoard Cast button all offer wireless and software-less casting options.

AV Control System Interoperability

These displays are Crestron Connected® as well as Extron and AMX certified for seamless integration. Network admins are always in control with the ability to send control signals such as on/off. switch inputs. push firmware and security updates. and get status from the display.

Centralized Device Control Manager

For IT admins. it’s tough managing the hundreds of devices and displays that live on the network. Now with myViewBoard Manager. an easy-to-use web-based application. IT can securely set up. manage and maintain all of the displays from a centralized dashboard.

Reliable 24/7 Operation Rating

Featuring a long lifespan. this professional-grade commercial display is designed for reliable use 24 hours a day. 7 days a week. Ideal in virtually any commercial application and environment. this commercial display delivers peace of mind with its robust and durable design.

Superb and Stunning Picture Quality

With 4K resolution. high brightness and 25% high haze anti-glare glass treatment. these displays deliver bright. clear and sharp images in any indoor environment.

Powerful Secured Embedded Platform

This display can execute several tasks at once while providing smooth content playback without the need for a PC or media player. The embedded SoC provides PC-like performance and power to run apps. while hardened custom Android OS firmware protects the display from viruses and security breaches by preventing unknown sources to be installed on the system.

Display
Panel type: ADS
LED backlighting type: Direct-LED
Display diagonal: 139.7 cm (55")
Display technology: LCD
Display resolution: 3840 x 2160 pixels
Display brightness: 450 cd/m²
HD type: 4K Ultra HD
Native aspect ratio: 16:9
Response time: 8 ms
Contrast ratio (typical): 1200:1
Contrast ratio (dynamic): 5000:1
Viewing angle. horizontal: 178°
Viewing angle. vertical: 178°
Display number of colours: 1.07 billion colours
Display diagonal (metric): 139 cm
Panel life: 50000 h
Native refresh rate: 60 Hz
Haze rate: 25%
Surface hardness: 3H
Ports & interfaces
HDMI ports quantity: 3
HDMI version: 2.1
HDMI input ports quantity: 2
HDMI output ports quantity: 1
Feature: USB port
USB ports quantity: 3
USB version: 2.0/3.2 Gen 1 (3.1 Gen 1)
USB connector type: USB Type-A. USB Type-C
Feature: Ethernet LAN
Ethernet LAN (RJ-45) ports: 1
Ethernet LAN data rates: 10.100.1000 Mbit/s
Feature: RS-232 interface
Feature: OPS module slot
Audio
Feature: Built-in speaker(s)
Number of built-in speakers: 2
RMS rated power: 20 W
Design
Product design: Digital signage flat panel
Placement supported: Indoor
Orientation: Horizontal/Vertical
Product colour: Black
Screen shape: Flat
Feature: VESA mounting
Panel mounting interface: 400 x 200 mm
Bezel width (bottom): 1.5 cm
Bezel width (side): 1.5 cm
Bezel width (top): 1.5 cm
Feature: Anti-glare screen
Mounting type: Wall
Performance
Purpose: Universal
Operating hours (hours/days): 24/7
Feature: HDCP
HDCP version: 2.2
Power
Power consumption (typical): 155 W
Power consumption (standby): 0.5 W
Power consumption (max): 250 W
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Computer system
Feature: Computer system
Computer system type: System on Chip (SoC)
Feature: Built-in processor
Processor model: Amlogic T982
Processor frequency: 1.9 GHz
Processor cores: 4
Internal memory: 4 GB
On-board graphics card model: ARM Mali-G52
Internal storage capacity: 32 GB
Operating system installed: Android 11
Weight & dimensions
Display width: 1233 mm
Display depth: 71.5 mm
Display height: 703.5 mm
Display weight: 13.4 kg
Packaging data
Package width: 1332 mm
Package depth: 156 mm
Package height: 819 mm
Package weight: 19.5 kg
Packaging content
Feature: Remote control included
Feature: Batteries included
Cables included: AC. HDMI. RS-232. USB Type-C
Feature: Mounting kit
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 20 - 80%
Certificates
Certification: cTUus. FCC. Energy Star 8.0. RoHS. Mexico NOM. Mexico Energy
Technical details
OPS slot: 1
Other features
Feature: Quick start guide
