NETWORK - ETHERNET CABLES

Cat.6A Pro S/FTP Patch Cord is composed of preeminent materials and fully-examined to Cat.6A Platinum S/FTP Patch Cord is composed of preeminent materials and fully-examined to conform with industrial standards. Offering higher bandwidth and better signal-to-noise margin. the Cat.6A cable is able to deliver ultrahigh and error-free performance in the most demanding network environments. specially for 10G application.


Features
Product colour: Grey
Cable length: 2 m
Cable standard: Cat6a
Cable shielding: S/FTP (S-STP)
Connector 1: RJ-45
Connector 2: RJ-45
Connector 1 gender: Male
Connector 2 gender: Male
Connector 1 form factor: Straight
Connector 2 form factor: Straight
Connector contacts plating: Gold
Jacket material: Low smoke zero halogen (LSZH)
Cable shape: Round
Conductor type: Stranded
Conductor material: Copper
Cabling technology: 10GBase-T
Ethernet interface type: 10 Gigabit Ethernet. Fast Ethernet. Gigabit Ethernet
AWG wire size: 26/7
Data transfer rate: 10000 Mbit/s
Frequency: 500 MHz
Feature: Power over Ethernet (PoE)
Power over Ethernet (PoE) type supported: PoE+. PoE++ (4PPoE)
Feature: Molded cable boot
Feature: Plug and Play
Country of origin: China
Certificates
Compliance certificates: RoHS. UKCA. CE. REACH
Weight & dimensions
Width: 11.7 mm
Depth: 8.2 mm
Height: 2000 mm
Weight: 100 g
Packaging content
Quantity per pack: 10 pc(s)
Packaging data
Package width: 380 mm
Package height: 300 mm
Package weight: 1.01 kg
Logistics data
Master (outer) case width: 300 mm
Master (outer) case length: 280 mm
Master (outer) case gross weight: 10.8 kg
Master (outer) case height: 490 mm
Products per master (outer) case: 12 pc(s)
Technical details
Feature: Sustainability compliance
